Product Features:
Intelligent man-machine interface, the operation will be between;
Automatic color identification, high positioning accuracy: the German labor easily measured color standard sensor positioning, can automatically distinguish 7 colors, positioning accuracy, error within ± 0.02mm;
Unique wrong hot function: in the absence of material circumstances, the pressure will automatically stop pressing hot mold;
Stable operation: the use of the Japanese well-step import of motor, ring standard, sending the standard stable and reliable;
The frequency of random adjustment, low noise: servo motor feed accurate, low noise, accurate feeding, error within ± 0.02mm, stepless adjustment, feeding speed can be adjusted.

Device parameters

Model	Dimensions（mm）	Heat Transfer Temperature	Machine Weight	Voltage	Heating Output Power	Air Pressure	Total Power	Throughput
PFT-590C-1	890×670×1480	100-180±3℃	155KG	AC220V	0.5KW	0.4-0.6mpa	1KW	900-1200片/h
